Fisherman FD1 Drone WaterProof Fishing UAV

Designed specifically for anglers, Fisherman FD1 Drone WaterProof Fishing UAV is a specialized waterproof fishing drone. Enhanced by a more robust propulsion system, this FD1 can handle heavier bait loads, extend flight durations, and maintain stability even in windy conditions.

–

Best Features

2 kg (4lbs)
Bait Capacity

Up to 5
Drops per Charge

IP67
Seawater-proof Aircraft

20 m/s (38mph)
Wind Resistance

1.6 km (1 mile)
Casting Range

Up to 30 min
Flight Time

–

More About This Product

Dedicated For Drone Fishing

Fisherman FD1 Drone WaterProof Fishing UAV eliminated unnecessary features and components not applicable to drone fishing. Specific algorithms were incorporated into FD1’s flight controller to guarantee the drone’s ability to uphold altitude and position when carrying heavy baits. Numerous advantages contribute to FD1 being hailed as one of the premier fishing drones in history.

2KG (4lbs) Bait Capacity

High-capacity lipo flight battery, combined with high-torque and high-kv motors powers FD1 to lift baits of up to 2kg. Catch more fish or bigger fish by attaching multiple baited hooks or a big live bait to the line.

Up To 5 Drops Per Charge

Thanks to large bait capacity and up to 30 mins flight time, Fisherman FD1 Drone WaterProof Fishing UAV can make 5 drops of 800 g (1.7 lbs) baits over 600 m (650 yd) on a single battery charge. Increase your fishing success to the next level.

1.6 Km (1 mile) Casting Range

Fisherman FD1 Drone WaterProof Fishing UAV can operate at a range of up to 1.6 km (1 mile). Land-based anglers can easily cast a long line and drop baits in any hard-to-reach fishing spots, without using a boat or kayak.

Rugged Body

The fuselage of Fisherman FD1 Drone WaterProof Fishing UAV is made out of marine-grade ABS to prevent cracking when lifting weights. The propellers are made out of carbon fiber for high stiffness. FD1 is far more durable than any other consumer-level drone in the industry.

–

All-Weather, All-Water Fishable

Fisherman FD1 Drone WaterProof Fishing UAV’s aircraft is certified as IP67 Seawater-proof, ensuring complete waterproofing. This enables it to seamlessly land on and take off from water surfaces, ensuring safe return flights to the shore.

With a Level 7 Wind Resistance rating, FD1 is equipped with a robust propulsion system and custom flight controller optimized for flight stability in winds reaching up to 20 m/s (38mph).

Benefitting from corrosion-resistant coatings, Fisherman FD1 Drone WaterProof Fishing UAV’s waterproof motors and internal electronics remain protected against the corrosive effects of salty sea air.

–

Heavy On Fishing, Light On Piloting

Fisherman FD1 Drone WaterProof Fishing UAV boasts exceptional stability achieved through the integration of multiple sensors. The GPS/GLONASS system, capable of receiving signals from up to 11 satellites each, accurately maintains the aircraft’s position. Additionally, a barometer ensures precise altitude control, while a gyroscope maintains balance under various conditions. Even novice fishermen without prior piloting experience can effortlessly operate FD1 with professional skill.

Bait dropping is made effortless with FD1’s simple remote-controlled button, allowing fishermen to attach fishing line to the bait release and release it with ease.

To counteract pendulum motion common in drones carrying payloads, Fisherman FD1 Drone WaterProof Fishing UAV features an Anti-Pendulum function, adjusting acceleration and deceleration to minimize this effect.

With its auto-release and return capabilities, FD1 can automatically release bait and return to shore when the battery level reaches a predetermined threshold or if connection is lost.

–

Product Highlights

Aircraft

Waterproof Rating: IP67
Drone Weight（include battery and propellers): 2050g
Axis Diameter: 450 mm
Max Ascend Speed: 4 m/s
Max Descent Speed: 4 m/s
Max Flight Speed: 10 m/s（GPS); 22 m/s（ATTI)
Max Tilt Angle: ATTI Fast Mode 25°；ATTI Slow Mode 12.5°
Max Altitude From Takeoff Point: 120 m (GPS) / 1.3 km (ATTI)
Max Wind Speed Resistance: 72km/h | 20 m/s | 39knot
Hovering Accuracy: ±0.5m
Max Flight Time: 30 mins (no wind & no load); (approx. 15 mins with 1.0kg, approx.12 mins with load of 1.5kg)
Max Flight Distance: 1.6 km
Max Payload Capacity: 2.0 kg
Satellite Positioning Systems: GPS/GLONASS
Flight Control: Hawk
Motor: #3509/740Kv
ESC: 40A (flux)
Propeller: #1242 carbon fiber quick release propellers
Working Temperature: -10℃ ~ 40℃
Battery Type: 4S 15.2V 6500mAh Lipo
Battery Weight: 640g
Charging Time: 90 min

Remote Control

Weight: 378 g (without battery）
Size: 174x89x190 mm
Frequency: 2405 – 2475 MHz
Band Wide: 5000 KHz
Coding Mode: GFSKEffective Distance: 1.3 km (No interference, open area)
Receiving Sensitivity: -105dBm
Transmitting Power: Less than 20dBm
Channel: 6Battery
Type: 6V (1.5V AAx4)

PL1-F Bait Release

Waterproof: IP67
Max Payload Weight: 2kg
Size: 60.7*36.2*50mm
Cable Length: 220mm
Weight: 90g

PL2-F Bait Release

Waterproof: IP67
Max Payload Weight: 2kg
Size: 122.5*50*39mm
Cable Length: 160mm
Weight: 150g
Sensor Size: 1/2.7; support WDR (Wide Dynamic Range)
Resolution: 2000TVL | 800×480
Lens: F/2.5 f/2.1
Input Voltage: 5~36V

Video Transmitter

Frequency: 5645 ~ 5965MHz
Channel: 40CH
Transmission Distance: 1.6km (No obstacles, no interference)
Power: 25/400/600mWInput Voltage: 7.4~26V
Size: 32*25*10.4mm (antenna 140mm)
Weight: 12.8g
Screen Size: 5″
Resolution: 800 * 480
Display Scale: 16:9
Brightness: 300cd /m²
Latency: <20ms
Lens: 8 times Fresnel lens, light transmittance 92%, no distortion of light
Antenna: 2 X RP-SMA male
USB: For charging（max charging current: 500mA）
Card Slot: Micro SD card (64G max)’Recording Resolution: VGA / D1 / HD optional
REC Sound: ON / OFF
Recording Section: OFF / 3min / 5min / 10min
Resolution: 30FPS
Compress Format: MJPEG
Video Format: AVI
Language: EN/CN
Power: DC5V / 2A（USB）
Battery: Built-in 3.7V / 2000 mAh Lipo Battery DVR ON – 2.5hour | DVR OFF – 3.5hour”

–
