RFLY-MICRO S1 RFLY Drone: Precision And Versatility In A Compact Drone

The RFLY-MICRO S1 RFLY Drone is an advanced UAV. It is designed for professionals who require a versatile and easy-to-operate UAV system. This cutting-edge quadcopter combines the latest in drone technology with a compact design. Thus making this RFLY Micro Drone ideal for a wide range of applications. Starting from surveillance to data collection. It includes impressive flight capabilities and robust features. The RFLY-MICRO S1 stands out as a top choice for both seasoned drone operators and those new to the field.

RFLY-MICRO S1 RFLY Drone: Advanced Flight Capabilities

The RFLY-MICRO S1 RFLY Drone is built for endurance and performance. This product has an endurance of up to 60 minutes at 1000m AMSL. It offers extended flight times. Thus ensuring that you can complete your missions without frequent interruptions. Its maximum all-up weight (AUW) of less than 2kg makes it lightweight yet powerful. This product is capable of maintaining stability and performance even in challenging conditions.

Designed to operate within a range of 3km VLOS (Visual Line of Sight). The RFLY-MICRO S1 RFLY Drone ensures you can cover extensive areas. Its GNSS navigation system provides precise location tracking and flight path control. Thus making it an excellent choice for both manual and autonomous missions. This RFLY Micro Drone's wind resistance of up to 8m/s ensures stable performance. Even in moderate wind conditions. Its max launch altitude of 4500m AMSL and operating altitude of 500m (or 120m AGL as per DGCA regulations) make it suitable for high-altitude missions.

RFLY-MICRO S1 RFLY Drone: Efficient And Reliable Operation

RFLY-MICRO S1 RFLY Drone includes proprietary hardware and a licensed firmware flight controller. Thus ensuring smooth and reliable operation. It includes vertical take-off and landing (VTOL) capability. This product includes a compact 5m x 5m launch and recovery area. All this allows for easy deployment in tight spaces. The RFLY Micro Drone can be assembled by a two-person crew in under five minutes. Thus making it quick to deploy in the field.

The RFLY-MICRO S1 RFLY Drone’s failsafe modes include a Return to Home function. This feature is triggered by communication failure or low battery. Thus ensuring the safe return of the drone in case of emergencies. The multiple onboard GPS units provide redundancy. Thus enhancing reliability and safety during flight operations.

Technical Specifications: RFLY-MICRO S1 RFLY Drone

• Product Name: RFLY-MICRO
• Model Name: RFLY-MICRO S1
• Type Certification: Yes
• Configuration: Quadcopter
• Endurance: Up to 60 minutes @ 1000m AMSL
• Max AUW: Less Than 2Kg
• Range: 3Km VLOS
• Navigation: GNSS
• Wind Resistance: 8m/s
• Max Launch Altitude: 4500m AMSL
• Max Operating Altitude: 500m | 120m AGL (As per DGCA)
• Max Cruise Speed: 8m/s
• Nominal Cruise Speed: 6m/s
• Propulsion System: Electrical
• Launch and Recovery: Vertical Take-off and Landing
• Launch and Recovery Area: 5m x 5m
• Operational Temperature: -10℃ to +55℃
• Assembling Crew and Time: Two-person crew, under 5 minutes
• Flight Controller: Proprietary hardware and licensed firmware
• Failsafe Modes: Return to Home (communication failure or low battery). Multiple GPS for redundancy
• Battery Type: Lithium-based
• GCS Hardware: Handheld controller with a 7-inch LCD screen, 6-15 hours endurance, 16 channels, 1050g weight
• Communication Frequency: 2.4 GHz
• Communication Encryption: 128-bit AES encryption
• Communication Link Capabilities: Command transmission, telemetry data, HD video
• GCS Software: RFLY NAVIGATOR
• Flight Modes: Position Mode, Fully Autonomous Mode. Waypoint Navigation Mode, RTH (Return to Home)
• GCS Features: Maps, UAV location, flight plan, battery level, speed and altitude, terrain following, geo-fencing
• User Control: One-click take-off and landing, set UAV altitude
• Payload: Surveillance day camera with 3-axis gimbal stabilization
• Payload Specifications: 1/1.7 inch Sony CMOS sensor, 8MP, 4K video recording, 6x digital zoom, 720/1080p video streaming
• Packing and Storage: Rugged hard case for all subsystems
• Technical Life: 700 hours or 5 years

RFLY-MICRO S1 RFLY Drone: Robust Communication And Control

RFLY-MICRO S1 RFLY Drone uses a 2.4 GHz frequency with 128-bit AES encryption. Thus ensuring that all data transmissions are protected from unauthorized access. The GCS (Ground Control Station) hardware includes a handheld controller. This handheld controller comes with a 7-inch LCD screen. Thus offering 6 to 15 hours of endurance and 16 communication channels. All within a lightweight 1050g package.

Communication link capabilities of the RFLY-MICRO S1 RFLY Drone allow control command transmission. Starting from the GCS to the UAV, telemetry data from the UAV to the GCS, and HD video streaming back to the GCS. The RFLY NAVIGATOR software enhances the user experience with features such as Google Maps integration, importation of .KML and .SHP files, real-time UAV location tracking, flight planning, battery level monitoring, and more.

RFLY-MICRO S1 RFLY Drone: Versatile Flight Modes

The RFLY-MICRO S1 RFLY Drone offers multiple flight modes. To suit different mission requirements:

• Position Mode for manual control with GNSS assistance.
• Fully Autonomous Mode for automated missions from take-off to landing.
• Waypoint Navigation Mode for precision route planning.
• Return to Home (RTH) for automatic return in case of emergencies.

These versatile flight modes make the RFLY Micro Drone suitable for various applications. Starting from routine surveillance to complex data collection missions.

RFLY-MICRO S1 RFLY Drone: High-Quality Payload And Stabilization

It has a surveillance day camera mounted on a 3-axis gimbal stabilization system. The RFLY-MICRO S1 RFLY Drone ensures stable and clear imaging even during flight. The payload specifications include a 1/1.7 inch Sony CMOS sensor with 8 megapixels. This feature is capable of recording 4K video and offering 6x digital zoom. The drone can stream video in both 720p and 1080p resolutions. Thus making it ideal for real-time monitoring and data collection.

RFLY-MICRO S1 RFLY Drone: Durable And Portable Design

The RFLY-MICRO S1 RFLY Drone is designed for field operations. It features a rugged hard case that securely holds all subsystems. This design ensures that the RFLY Micro Drone is easy to transport and quick to deploy. Even in challenging environments. With a technical life of 700 hours or 5 years, the RFLY-MICRO S1 is built to last. Thus offering long-term reliability and performance.

RFLY-MICRO S1 RFLY Drone: Buy This Product Now!

The RFLY-MICRO S1 RFLY Drone stands out as a precision-engineered drone, proudly type certified and manufactured in India by RFLY. This certification ensures that the drone meets stringent industry standards, making it a reliable choice for various applications. Built with the expertise and innovation of Indian manufacturing, the RFLY-MICRO S1 combines advanced technology with local craftsmanship, delivering exceptional performance in a compact form.

The RFLY-MICRO S1 RFLY Drone is a powerful and versatile tool that combines advanced technology with a user-friendly design. Its impressive flight capabilities, secure communication, and high-quality payload make this RFLY Micro Drone an ideal choice for professionals in various industries, from surveillance to environmental monitoring. Whether you're conducting detailed surveys or engaging in routine inspections, the RFLY-MICRO S1 offers the performance and reliability you need to succeed. Explore the potential of the RFLY-MICRO S1 and elevate your drone operations to new heights.
